Knee MRI/Meniscus

[Tear_17] Ramp lesion_Normal anatomy and mean length_01

MSK MRI 2021. 10. 19. 20:26

The meniscotibial ligament attachment merged with the posterior meniscocapsular attachment to form a common attachment at the meniscocapsular junction.

The posterior meniscotibial ligament attachment to the PHMM had a mean length of 14.0 ± 5.4 mm at its insertion on the posterior tibia.
The meniscotibial tibial ligament attachment was located 5.9 ± 1.3 mm inferior to the articular cartilage margin of the posterior medial tibial plateau.

The posterior meniscocapsular attachment to the PHMM had a mean length of 20.2 ± 6.0 mm.
The posterior horn of the medial meniscus was 21.3 ± 2.0 mm.
